 Teklynx Label Matrix 8.00
Bar Code Labeling Software LABEL MATRIX 8 is the most powerful, easy-to-use RFID and label design software package in the industry. Its helpful design and database connection wizards, along with a simple interface, allow users to quickly design bar code, compliance or RFID labels. If you are looking for an easy-to-use, wizard driven software solution for UHF and HF RFID encoding and label design, the choice is simple - TEKLYNX LABEL MATRIX 8.
Teklynx Label Matix 8.00 Features & Benefits
NEW! Teklynx Label Matrix 8.00 is GS1/UCC Certified for EAN.UCC System Users
Label Matrix 8.00 labeling software gives you the power to design and print labels with ease and flexibility to meet your most demanding labeling needs. Whether you need address labels for your small business or thousands of inventory labels for a multi-site warehousing plant, Label Matrix can do the job.
Easy to Learn and Use even for beginners — familiar Windows icons, tab dialogs and a drag-and-drop interface make LABEL MATRIX instantly recognizable to anyone who has used a Windows software package.
Comprehensive Bar Code Support for over 45 symbologies including Code 39, Code 128, UPC A, UPC E, UCC/EAN-128, PDF 417, Data Matrix, MaxiCode, RSS-14 Composites and more.
Database Connectivity Options include 32-bit OLE DB support for Access, ASCII, dBase, Excel, FoxPro, ODBC, SQL server and others.
Enhanced Printer Support for more than 1000 thermal and thermal transfer printers, as well as any Windows printer, allows you to maximize your printer’s performance and print large runs of labels in a very short time.
Advanced Integration Features for automating print jobs (AutoPrint), logging data to a file (Write Data), and integrating label printing with other programs via command line calls (LMWPrint).
System Requirements
IBM-compatible PC, 486 or better
Microsoft Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, Windows XP, and Windows Vista
16 MB RAM with Windows 95 (32 MB recommended)
32 MB RAM with Windows 98 or Windows Me (64 MB recommended)
64 MB RAM with Windows NT 4.0, Windows 2000 or Windows XP (128 MB recommended)
VGA monitor or better
Hard drive with at least 25-50 MB free disk space, depending on the options you choose to install
CD-ROM drive
NEW! IN LABEL MATRIX 8.0
- Enhanced RFID capabilities: LABEL MATRIX 8 features an easy-to-use interface for printing and programming RFID tags. With TEKLYNX’ free DSP utility you can add support for new printers and RFID tags as they become available.
- TextArt: Offers a full complement of text art features, including shaped text with user-definable sweep angles, rotated characters, and new text fill, outline and shadow options.
- Label Backgrounds: Single-label layout designs can be saved as label backgrounds and serve as a "base layer" outline to make the label design process easier. LABEL MATRIX also supports round label formats which are useful for DVD/CD labels.
- Live Print Preview: Allows users to see how label designs will look when they are printed, including “live” variable data in any Keyboard and Database origin images. For labels that contain Keyboard Input data or data from a Keyed Access database, the Print Preview data input screens allow users to select the data/records that appear in the preview.
- Bundle Save: Users have the option to save a label design and any external files used by that design to a single folder. This gives the freedom to quickly port label designs and related files to another workstation.
- Expansion Variables: Creating an expansion variable "shortcut" allows users to assign names to value functions, and use the names any place a value or function within an expression would normally be used. This reduces the size of large expressions with significant amounts of repeating code.
- SQL Query Builder: Enables users who are not familiar with the required SQL syntax to create customized SQL statements.
- New Drivers Added:
Printer drivers have been added for the following families:
- Allen
- Argox
- Avery
- Bancolini
- Brady
- Citizen
- Datamax
- Easyprint
- Godex
- Imaje
- Industrial Labeling Systems
- Intermec
- Monarch
- Paxar/Monarch
- Printronix
- Sato
- TEC
- Thermo-Tex
- Toshiba
- TTF
- Validated Technologies
- Vitadresse
- Zebra
Teklynx Label Matrix 7.02 Screen Shot (.html 67KB)
Teklynx Label Matrix 7.02 Data Sheet (.pdf 728KB)
Teklynx Label Matrix 7.02 User Guide (.pdf 858KB)
Teklynx Label Matrix 7.02 Features Matrix (.html 42KB)
Teklynx Label Matrix 8.0 Data Sheet (.pdf 1.7MB)
Teklynx Label Matrix 8.0 User Guide (.pdf 1.02MB)
Teklynx Label Matrix 8.0 Features Matrix (.html 44KB)
*Order Online Label Matrix, Version 8.00 (P/N LM8) 32 Bit, North America, Single User Edition.
|
|  | | Label Matrix Version 8.00, 5 User, North America
| | |  | | Label Matrix, V 8.00, 5 Additional Users, North America & International
| | |  | | Label Matrix V 8.00, 10 Additional Users, North America & International
| | |  | | Label Matrix V 8.00, 25 Additonal Users for North America and International
| | |  | | Label Matrix V 8.00, Keyed International
| | |  | | Label Matrix V 8.00, PrintPack, North America
| | |  | | Label Matrix PowerPro V 8.00, Single User, North America
| | |  | | Label Matrix PowerPro V 8.00 (5 User Network)
| | |  | | Upgrde: Label Matrix 8.00 Software Upgrade (Single User, Version 5 to Version 8)
| | |  | | Upgrade: Label Matrix 8.00 Software Upgrade (Single User, Version 7 to Version 8)
| | |  | | Teklynx Lablel Matrix Quick Draw 8.0
| |
|
