 Intermec EasyCoder PM4i
Industrial PrinterNEW The Intermec EasyCoder PM4i, formerly EasyCoder® 3400e, is an industrial printer designed to excel in demanding applications and environments. Utilizing the latest technology, the PM4i features a strong and proven mechanical platform, and powerful newly developed electronics.
The EasyCoder PM4i printer acts as a "smart client" executing user-defined programs. This means your PM4i printer eliminates the personal computer, operates additional hardware (e.g. scanners, other printers, conveyors), accesses information from network host, and retains the ability to change as needed with the application for additional functionality. When using the EasyLAN Wireless option for the PM4i, any attached peripheral devices also become part of the wireless infrastructure.
Printer command languages do not restrict the EasyCoder PM4i bar code label printer. The printer can be changed to understand and replace competitive and older Intermec printers without requiring any changes to the host programming or label formats that are currently being used.
The EasyCoder PM4i includes integrated wired or wireless EasyLAN networking. The EasyLAN Wireless interface uses an integrated standard 802.11b radio. This radio provides 128-bit WEP encryption of the information relayed through the network. Intermec’s wired and wireless technology ensures secure printing and network infrastructure for all environments.
This is an extremely versatile bar code label printer. There are up to five interface ports that can be used simultaneously. The EasyCoder PM4i includes serial, parallel, USB, internal EasyLAN Ethernet, and EasyLAN Wireless. The magnetic QuickMount printhead eliminates hassles and the need to call a service technician. The printhead is replaced quickly and easily with the magnet and u-brackets ensuring proper alignment. The double-clutching ribbon mechanism means that you are no longer restricted to ribbon types based on how they are wound. The handy, inexpensive and PC-compatible Compact Flash memory technology provides quick and easy upgrades of firmware, fonts and memory.
Intermec EasyCoder PM4i Features & Benefits
Superior throughput eliminates wait time at the printer
Heavy-duty metal construction withstands harsh / rugged environments
Integrated EasyLAN™ Ethernet, USB and serial interface standard
CompactFlash™ memory for quick and easy firmware, font and memory upgrades
Supports stand-alone printer applications
Easily adapts to changing host environments and applications
Emulates and replaces competitive and older Intermec printers
Utilize up to five interface ports simultaneously, including internal EasyLAN Wireless
Magnetic QuickMount™ printhead for easy printhead installation
User selectable printer language
Double-clutching ribbon mechanism supports ribbons wound in either direction
Replaces legacy printer EasyCoder® 3400e
Environment
Temperature: +5°- 40°C (+40°- 104°F)
Humidity: 20-80% RH non-condensing
Noise: 50 dB (printing), no noise standby
Interfaces
Standard:
• RS-232, up to 115.2 kB/s
• USB 1.1
• EasyLAN Internal Ethernet 100/10BaseT
• I2C-bus for cutter
• Wand interface for EasySet™ System
Optional:
• EasyLAN Wireless, internal 802.11b Wireless Ethernet
EasyLAN Ethernet Network Interface:
Internal High Speed Ethernet
Ethernet: RJ-45 connector for 10baseT Ethernet or 100baseTX Fast Ethernet
Supported protocols: TCP/IP-suite (TCP, UDP, ICMP,IGMP, etc.), LPR/LPD,
FTP, BOOTP, DHCP, HTTP, SNMP, SMTP.
SNMP-MIB II supported (over UDP/IP), private enterprise MIB included
Memory
Standard:
4MB Flash
8MB SDRAM
1 Compact Flash slot
Optional:
Additional FLASH memory up to 16MB (8+8)
1GB Compact Flash memory
Physical Characteristics
Dimensions: LxHxW: 54.3 x 26.1 x 29.8 cm (21.38 x 10.28 x 11.73 in)
Weight: 13.5 kg (29.76 lbs.)
Power:
115/230VAC auto-switch w/PFC
Voltage range: 90-264VAC.
Frequency Range: 45-65 MHz
Print Specifications:
Max. Width: 104 mm (4.09 in) at 203 dpi; 105.7 mm (4.16 in) at 300 dpi.
Max. Length w/std memory: 2520 mm (99.2 in) at 203 dpi; 1092 mm (43.0 in) at 300 dpi.
Max. Length w/16MB SDRAM: 4095 mm (161.2 in) at 203 dpi; 2730 mm (107.5 in) at 300 dpi.
Supported Bar Code Symbologies
1-dimensional:
Codabar, Code 11, Code 39, Code 93, MSA (modified Plessey), Code 128, Code 128 Subset A-C, DUN-14/16, UPC/EAN Codes (EAN 8, EAN 13, UPC
Version A, UPC Version E), EAN-128, EAN-128 Subset A-C*, Industrial 2 of 5,
Interleaved 2 of 5, Interleaved 2 of 5 A, Matrix 2 of 5*, Planet, Postnet,
Straight 2 of 5*, UCC-128 Serial Shipping Container Code, RSS, HIBC Code 39
(IPL only), HIBC Code 128 (IPL only), JIS-ITF (IPL only)
2-dimensional:
Code 16K, Code 49, Data Matrix, MaxiCode, PDF417,
QR Code, MicroPDF417, EAN.UCC CompositeRelated Products
On Site Plans (Call for pricing)
Intermec Medallion On Site Service Contract plans provide a variety of commitment and coverage levels of industry-leading repair service.
Depot Plans
Intermec Medallion Depot Service Contract plans provide a variety of commitment and coverage levels of industry-leading repair service.
Preventive Maintenance
SiteCare visits help prevent small problems from growing into large ones, and allow customer staff to focus on more business-critical daily activities.
Intermec EasyCoder PM4i Data Sheet (.pdf 124KB)
Intermec EasyCoder PM4i Installation Instructions/User Guide (.pdf 8.4MB)
Intermec Direct Thermal Labels
Intermec Thermal Transfer Labels
Intermec Thermal Transfer Ribbons(Wax, Wax/Resin, Resin)
***Intermec Label & Ribbon Order Form (.html 14KB)***
*Included in Printer Box:
US Power Cord, RS-232 Cable, User & Installation manuals, Printer Companion CD, Cleaning Card, , Product registration card, Declaration of Conformity.
Order Online the Intermec EasyCoder PM4i featuring: EasyCoder PM4i Direct Thermal-Thermal Transfer Industrial Printer (Fingerprint Firmware, Serial Interface, No I/O Option 1, No I/O Option 2, 16MB RAM, 4MB Flash, Paper Hanger, No Option 1, No Option 2 and TT 203 dpi).
|
|  | | Intermec PM4C810000301020 EasyCoder PM4i - Label printer - Monochrome - Direct thermal; Thermal transfer - 8ips - 203 dpi - 4.09 in. width - Ethernet; Serial; Parallel; USB
| | |  | | Intermec PM4C810000301120 EasyCoder PM4i Direct Thermal-Thermal Transfer Industrial Printer (Fingerprint Firmware, EasyLAN Ethernet Interface, No I/O Option 1, No I/O Option 2, 16MB RAM, 4MB Flash, Paper Hanger, Paper Rewind Self Strip + LTS, RTC and TT 203 dpi)
| | |  | | Intermec PM4C900000300020 EasyCoder PM4i - Label printer - Monochrome - Direct thermal; Thermal transfer - 76 labels per minute(at 4 x 6 in. GM1724 label) - 203 dpi - 4.09 in. width - Serial; USB; Ethernet 10/100 Base-T
| | |  | | Intermec PM4C901000300020 EasyCoder PM4i Direct Thermal-Thermal Transfer Industrial Printer (IPL Firmware, Serial Interface, Parallel Interface, No I/O Option 2, 16MB RAM, 4MB Flash, Paper Hanger, No Option 1, No Option 2 and TT 203 dpi)
| | |  | | Intermec PM4C910000300020 EasyCoder PM4i - Label printer - Monochrome - Direct thermal; Thermal transfer - 76 labels per minute(at 4 x 6 in. GM1724 label) - 203 dpi - 4.09 in. width - Serial; USB; Ethernet 10/100 Base-T
| | |  | | Intermec PM4C810000300020 EasyCoder PM4i Direct Thermal-Thermal Transfer Industrial Printer (Fingerprint Firmware, EasyLAN Ethernet Interface, No I/O Option 1, No I/O Option 2, 16MB RAM, 4MB Flash, Paper Hanger, No Option 1, No Option 2 and TT 203 dpi)
| | |  | | Intermec PM4C810000300030 EasyCoder PM4i Direct Thermal-Thermal Transfer Industrial Printer (Fingerprint Firmware, EasyLAN Ethernet Interface, No I/O Option 1, No I/O Option 2, 16MB RAM, 4MB Flash, Paper Hanger, No Option 1, No Option 2 and TT 300 dpi)
| | |  | | Intermec 1-110501-00 Cleaning Card, 115 x 152 mm, Box of 25. For use with Intermec C4, E4, 3400e, PM4i
| | |  | | Intermec 225-746-001 PC41A/ PC4C/PD41A/ PD4B EasyLAN 10i2, External Ethernet Adapter (Power supply not required)
| | |  | | Intermec 1-010043-900. Replacement Printhead Compatibility: PF4i ,PF4Ci, PM4i. (200dpi, 7Mil)
| | |  | | Intermec 1-010044-900 Replacement Printhead (300 dpi, 7 mil) for the PM4i Industrial Printer
| | |  | | Intermec 1-974024-018 RS232 Cable 1,8m (DB9F - DB9M) ASSY RoHS
| | |  | | Intermec 1-974022-018 Cable, IEEE 1284 Parallel 1,8m RoHS
| |
|
